IBM ThinkPad Dock II Type 2878 for T40 / T41 / T42 / T43 / R50 – 62P4551 / 13R0291

The IBM ThinkPad Dock II (Type 2878) is the full-size docking station for classic T4x, R5x and A3x ThinkPads, with DVI and VGA video, USB 2.0 and the complete set of legacy ports for older peripherals.

Key Specifications

• Part Numbers: 62P4551 / 13R0291
• Model: Type 2878
• Compatible With: IBM ThinkPad T30, T40, T40p, T41, T41p, T42, T42p, T43, T43p, R50, R50p, R51, R52, A30, A30p, A31, A31p
• USB: 4 x USB 2.0
• Video Outputs: 1 x DVI, 1 x VGA
• Networking: Ethernet (RJ-45), modem (RJ-11)
• Audio: Headphone out
• Other Ports & Features: Serial (RS-232), parallel (IEEE 1284), PS/2
• Power: IBM/Lenovo round-tip (barrel) AC adapter
• Security: Key lock

Uses the IBM docking connector of the T30/T4x/R5x/A3x generation. Not compatible with T60 or later.
